Magnetic Dual Coil Latching Relay 12V DC 60A 3W SPDT For Smart Power Meter

Brand Name : NBC

Model Number : NBC9-B-60-DC12V-2

Certification : CQC

Place of Origin : China

MOQ : 100pcs

Price : negotiable

Payment Terms : T/T

Supply Ability : 500k per month

Delivery Time : 5-8days

Packaging Details : standard or customization

Keyword : SPDT Power Relay

Rated coil voltage : DC12V

Rated current : 60A

Contact form : 1B

Coil power : 3W Double coil

Weight : Aprox.40g

Enclosure type : Dust-proof

Feature : Environmental, power saving

Contact Now

Magnetic Dual Coil Latching Relay 12V DC 60A 3W SPDT For Smart Power Meter

SPDT Power Relay Features:

1. Environmental, power saving

2. 1.5W or 3W coil power for option

3. NO or NC can be switched by hand

SPDT Power Relay introduce:

A relay is an electrical control device, which is an electrical appliance that makes a predetermined step change of the controlled quantity in the electrical output circuit when the change of the input quantity meets the specified requirements. It has an interactive relationship between the control system and the controlled system. Usually used in automated control circuits, it is actually an "automatic switch" that uses a small current to control the operation of a large current. Therefore, it plays the role of automatic adjustment, safety protection, and conversion circuit in the circuit.

SPDT Power Relay Specification:

Contact Rating
Contact Form	1A/1B
Contact Resistance Max	20mΩ
Contact Material	AgSnO2, AgNi
Contact Load Capacity(Resistance)	90A 250VAC ,60A/250VAC
Switching Power Max.	22500VA
Switching Voltage Max.	250VAC
Switching Current Max.	90A
Life expectancy	Electrical	1x10^4 (electric meter) 1x10^5 (60A 250VAC)
	Machanical	1x10^5 (electric meter) 1x10^6

Outlines dimensions

Magnetic Dual Coil Latching Relay 12V DC 60A 3W SPDT For Smart Power Meter
